How do you hook up a Leviton dimmer switch

Red is the switched lead (or a traveler in a 3-way installation), and is attached to the switched hot going to the light. Red with white is a traveler, used for 3-way installations. In your situation, you’ll just cap this one off. Green is ground, and is attached to the grounding conductor.

What is the red and white wire on a dimmer switch?

Red is the switched lead (or a traveler in a 3-way installation), and is attached to the switched hot going to the light. Red with white is a traveler, used for 3-way installations. In your situation, you’ll just cap this one off. Green is ground, and is attached to the grounding conductor.

Do you need special wiring for a dimmer switch?

New dimmers have either a green grounding wire or a green ground screw that you’ll have to connect to a grounding source if one is available. Houses wired with plastic-sheathed cable almost always have bare copper ground wires that you’ll connect to the toggle dimmer switch.

Why does my dimmer switch have 2 black wires?

The two black wires connecting to the black leading to the switch are supplying power to the switch/dimmer. The blue wire from the switch connected to the other black wire is the switched-hot going to the light. The green wire is the ground. It all looks normal.

Where does red wire go on dimmer switch?

Red is the switched lead (or traveler in a 3-way installation), and is attached to the switched hot going to the light. Red with white is a traveler, used for 3-way installations. In your situation, you’ll just cap this one off. Green is ground, and is attached to the grounding conductor.

How do you wire a switch with two black wires?

Connect the top screw to the wire that feeds to the light. Connect the bottom screw to the hot wire. When you turn the power back on, and if you want to swap the direction of the switch (as in press down to turn off, or turn on), turn off the power and switch the two black wires.

Which wire is positive when both are black?

If the multi-colored wire is black and red, the black wire is the negative wire, while the red one is positive. If both wires are black but one has a white stripe, the striped wire is negative, while the plain black wire is positive.

Does a dimmer switch need 3 wires?

When installing a Dimmer switch, all you’re really doing is controlling the amount of voltage flow to a light which makes it dim at a low setting to a fully bright light at maximum setting. Now a typical circuit will contain a 3-wire cable known as romex.

Does it matter what wire goes where on a light switch?

One of the black wires is the “hot” from your circuit breaker panel and the other black wire goes to the light fixture (load). If you’re using a regular light switch, then it doesn’t matter which wire goes to which screw, since the switch is just opening and closing the circuit to make the light turn off or on.

Can I install a dimmer on any light?

Most light fixtures will work with standard dimmer switches, including those with halogen and incandescent lamps. … If you install line-voltage track and rail lights with incandescent bulbs, you can use dimmer switches to control their brightness. Just be sure to use a line-voltage dimmer as well.

Article first time published on

How do push button dimmers work?

A short button press turns the dimmer on and off. When turned on, the dimmer will ramp up to the same brightness level as when it was last turned off. A long button press will cause the dimmer brightness to go up or down. … Release the button and then hold down again to change the dimming direction.

What does a load correction device do?

The load correction device provides improved dimming performance and load stability for low-power dimmable CFL or LED lighting loads across a wide dimming range. The load correction device also provides a positive off-state for phase-controlled dimmer channels controlling electronic lighting loads.

What do I connect the red wire to?

Normally you’ll see a red wire in places you would expect a ceiling fan. But in places like a bathroom or a wall light, if you see a red wire, it’s a good bet that the red wire is the wire that’s connected to the light switch.

What does a red and white wire mean?

White Wires With Red Or Black Tape To indicate this, they will have red or black tape to show that it is a hot wire, not a neutral. Generally, these wires are not the main hot wire, but they can be used as the secondary hot wire on a 240-volt outlet or appliance.

What are the black and red wires in a light switch?

• Black Wire – This is the hot or load wire.
• White Wire – This is the neutral wire.
• Bare Copper (Green) Wire – This is your ground wire.
• Red Wire – This wire is used for 3 or 4 way switches and will connect the switches together so they can each control your lights.

Which is the live wire black or red?

Black (neutral) Red (live) Green and yellow (earth)

What are the red wires in a light switch?

What are Red Wires? Red wires are usually used as secondary hot wires. Red wires are also hot and should be clearly marked to avoid the dangers of electrocution. Red wires are commonly used when installing ceiling fans, where the light switch maybe.

What color wire is the common wire?

Red, Black, and White are the colors of switch wiring for three-ways. Red and Black are connected to the switches if the White is used for neutral. The White is often referred to as Common, but the colored wires are also used as hot wires.

What happens when you have two black wires?

You should see two black wires, each connecting to a different screw on the side of the switch. These are called terminal screws. You will also see two white (neutral) wires that connect to one another in the box. … These are ground wires.

Do I connect the blue wire to the black wire?

Connect the blue wires together or the blue wire to the black wire for lights. Follow the same step for ceiling fans without lights. This will allow you to add a light kit later on without having to rewire the fan. Tuck the wires back into the box.

Does the blue wire go to the black wire?

Note that the blue wire is connected to the black fan wire so that they can both be operated by the same switch. Connect the ceiling fan blue wire to both the black fan wire and the black wire from the ceiling. This connection allows both the ceiling fan and light kit to be powered by a single light switch.

What happens if you mix up hot and neutral wires?

This happens when the hot and neutral wires get flipped around at an outlet, or upstream from an outlet. Reversed polarity creates a potential shock hazard, but it’s usually an easy repair. Any $5 electrical tester will alert you to this condition, assuming you have a properly grounded three-prong outlet.

What do the colors on wires mean?

Electrical wiring comes in one of several colors: Black Wires – when you see a black wire, always assume it’s live. … Blue Wires – always assume they are live if you have power. Blue wires are also fed through a conduit, usually bringing power to three or four-way switches. Green Wires – green wires are grounding wires.

How can you tell which wire is hot and which is neutral?

Most likely the neutral wire is white and the hot wire is red or black, but test to make sure. Identify the neutral wire in the fixture by looking at the wires. In most modern fixtures the neutral wire will be white and the hot wire is red or black. In some types of fixtures, both wires will be the same color.

Why are all the white wires connected together?

If you see them tied together, it signals that you’ve got a wired switch loop. Now, not all white wires are neutral. … And that’s because of the switch loop. Furthermore, for this reason, the two wires are connected without causing any trouble.

What happens if you wire a light switch wrong?

If a light switch is wired up wrongly, a short circuit may takes place if you give phase and neutral to the switch terminals. Always connect neutral wire to the one terminal of the light and phase to the one terminal of the switch and off wire to the other terminal of the switch to the light other terminal.
