How do you reset the drum on a Brother HL 5340d

To reset the drum counter, press and hold down Go for about 4 seconds until all the LEDs light up. Once all four LEDs are lit, release Go. Close the front cover. Make sure that the Drum LED is now off.

How do I reset my brother hl 5340D?

Brother HL-5340D and HL-5370DW Toner Reset Instructions When all three LEDs are lit, release the Go-button. Double-click the Go-Button button, and the three LEDs should be lit again. Press the Go-Button button six times. Close the front cover and the toner counter must be reset.

How do I get my Brother printer to recognize my new drum?

1. Make sure the machine is on.
2. Close up the front cover.
3. Hold down the “OK” button and the “up” arrow at the same time.
4. Press the “OK” button to select “Drum”.
5. Select the “down” button to reset the drum counter.

How do you reset the drum light on a Brother printer?

1. Close the front cover.
2. Make sure the machine is turned on.
3. Press. (Settings). …
4. Press All Settings. (This step might be skipped in some models.)
5. Choose Machine Info. or Machine Information => Parts Life.
6. Press and hold Drum or Drum Life until the machine’s display message changes.
7. Press Yes.
8. Press.

Why does my Brother printer keep telling me to replace the drum?

The Brother machine will display a ‘Replace Drum’ or ‘Drum Stop’ message when the machine has printed approximately 15,000 pages. The drums should be replaced as a set in order to maintain print quality. Unlike the toner cartridges, the drum change is not automatically detected by the machine when they are replaced.

How do I reset my Brother HL 5370dw?

Make sure that all the LEDs are off. Press Go eight times. Make sure that all the LEDs light up to indicate the print server has been reset to its factory default settings. The printer will restart.

How do I reset my brother hl 5350dn toner?

1. Open the front cover and leave open while completing the following steps.
2. Turn the printer off.
3. Hold the GO button while turning the printer on.
4. When 3 led light up release the GO button.
5. Press the ‘go’ button twice (3 LED’s should light up again).

How do you reset the drum on a Brother printer HL l2370dw?

1. Make sure the machine is on.
2. Close up the front cover.
3. Hold down the “OK” button and the “up” arrow at the same time.
4. Press the “OK” button to select “Drum”.
5. Select the “down” button to reset the drum counter.

How do I reset my Brother HL l2320d drum?

1. Open the front cover.
2. Press and hold the “Go” button until all LEDs light up. Once they are lit, release the button.
3. Close the front cover.
4. The Drum LED should now be off.

How do you reset the drum on a Brother printer HL L5100DN?

1. Make sure the machine is turned on.
2. Open the front cover.
3. Press and hold OK for about two seconds to display the [Drum Unit] option, and then press OK.
4. Press for [Reset] to reset the drum counter.
5. Close the front cover of the machine.

Article first time published on

How do you reset the drum counter on a Brother HL l2380dw?

1. Make sure the front cover is closed.
2. Press the “X” on the printer to display to interrupt the “replace drum” message.
3. Press the tool button (settings) > All Settings > Machine Info. > …
4. Hold down the # button on the keypad until the LCD message changes to the reset menu.

How do you reset the drum on a Brother printer mfc 7360N?

BROTHER MFC-7360N/MFC-7362N Open the machines front door where you would replace the cartridges. On the top panel you will see a “clear/back” button. Press it and on the display you will see a reset menu come up. Arrow to desired item (toner, drum etc) and press the OK button.

How do you reset the drum on a Brother MFC L2710DW?

1. Make sure the machine is turned on.
2. Close the front cover.
3. Press OK and the Up arrow key at the same time.
4. Press OK to select Drum.
5. Press the Up arrow key to reset the drum counter.

What happens if you don't replace the drum in a printer?

Without a drum unit, the toner powder in the cartridge cannot be transferred onto the page. The two parts work together to create a print! You can’t have one without the other and expect the printer to work properly.

How do you reset the drum counter on a Brother HL 2280dw?

1. Make sure the machine is on, then open the front cover and push “clear” button.
2. Confirm you are installing a new drum unit by pressing the “up” arrow.
3. When the screen says “Accepted”, close the front cover and you can now start printing!

What happens when a printer drum goes bad?

What happens when a printer drum goes bad? When the drum wears out, you’ll begin seeing lines or faults repeated across the page. Replace the drum unit when you get white lines on your pages.

How do you reset the drum on a Brother HL 4150CDN?

1. Press the “+” key to find “Machine Info”.
2. Press “OK”.
3. Press the “+” key to find “Reset Parts Life”.
4. Press “OK”.
5. Press the “+” key to find “Drum Unit”.
6. Press “OK”.
7. Press the “+” key to reset the drum counter.

How do I reset my Brother printer toner?

1. Switch-off the printer.
2. Press and hold the on/off button.
3. When all the LEDs turn on, open the cover and remove the toner cartridge + drum unit.
4. Release the on/off button.
5. Re-install the toner cartridge + drum unit back into the printer and close the printer cover.

How do I reset my brother 5250DN?

1. Step 1: Open the front door.
2. Step 2: Remove the drum unit.
3. Step 3: Press the Go button until all the lights are amber.
4. Step 4: Release the Go button.
5. Step 5: Insert new drum unit.
6. Step 6: Close the front door.

How do I print a configuration page on Brother HL 5370dw?

Hold down Go for 10 seconds. Release Go when the machine prints a Network Configuration page. If you release Go in less than 10 seconds, the machine will print if you have any reprint data. For details on how to print a Printer Settings page, please click here.

How do I reset my brother hl 2130 drum unit?

1. Make sure the machine is on, then open the front cover.
2. Press and hold the “Go” button for about 4 seconds or until all the LEDs light up.
3. Release the “Go” button and close the front cover.
4. If the drum light is off, the drum unit is reset.

How do you reset the drum on a Brother printer HL 2240?

Brother HL-2240 – Reset Drum Simply open the front cover, and hold the “GO” button until all four LED’s are lit. Release the “GO” button and close the front cover.

How do you reset the drum on a Brother printer HL l2375dw?

1. Make sure the machine is turned on.
2. Close the front cover.
3. Press OK and the Up arrow key at the same time.
4. Press OK to select Drum.
5. Press the Down arrow key to reset the drum counter.

How do you reset the drum on a Brother printer HL l2360dw?

1. Make sure that the machine is turned on.
2. Open the front cover.
3. Press and hold OK for about two seconds to display Drum Unit, and then press OK.
4. Press the Up arrow key to display Reset and reset the drum counter.
5. Close the front cover.

How do you reset the drum counter on a Brother HL l2360dw?

1. Open the front cover.
2. Press and hold the “OK” button for 2 seconds to display the “Drum Unit” option, then press “OK”.
3. Press the “up” arrow button to reset the counter.

How do you reset the drum on a Brother printer HL 6180dw?

1. For the models with LCD: Hold down Go until the Drum Clear message is displayed on LCD, then release Go.
2. For the models without LCD: Press and hold down Go for about 4 seconds until all the LEDs light up. Once all six LEDs are lit, release Go.

How do I reset my Brother HL l2365dw drum?

1. Make sure that the machine is turned on.
2. Open the front cover.
3. Press and hold OK for about two seconds to display Drum Unit, and then press OK.
4. Press the Up arrow key to display Reset and reset the drum counter.
5. Close the front cover.

How do you reset the drum on a brother tn660?

1. Open the front door of the toner compartment.
2. The printer screen should read “The front cover is open”.
3. Press the “Clear” key on the front panel of the printer.
4. The printer will say: “Replace the drum?”

How do you reset the drum on a brother mfc 7365dn?

1. Make sure the printer is on, then open the front cover and push “clear” button.
2. Press “1” to confirm you are installing a new drum.
3. When the screen says “Accepted”, close the front cover and you can now start printing!

How do you reset the drum life on a Brother MFC 7340?

Press 1 to reset the drum counter. If your Brother machine doesn’t have a numeric keypad: Press the Up Arrow Key to reset the drum counter.

How do you reset the drum counter on a Brother MFC l2740dw?

1. Press the “X” on the printer to display to interrupt the “replace drum” message.
2. Press the tool button (settings) > All Settings > Machine Info. > Parts Life.
3. Hold down the # button until the LCD message changes.
4. Press “Drum” and then select “Yes”
5. Select the home button.
