What are the three types of shock protection boundaries

There are three electrical shock hazard boundaries depending on the voltage of the appliance and termed the limited approach boundary, the restricted approach boundary, and the prohibited approach boundary.

What is a shock protection boundary?

A shock protection boundary to be crossed by only qualified persons (at a distance from a live part) which, when crossed by a body part or object, requires the same protection as if direct contact is made with a live part.

What are the four protection boundaries?

Flash protection boundary (outer boundary) The flash protection boundary is the farthest established boundary from the energy source. …
Limited approach boundary. …
Restricted approach boundary.

What are the three limits of approach boundaries?

The NFPA 703® recognizes three arc flash boundary levels: the limited approach boundary, the restricted area, and the prohibited area boundary.

What is the restricted boundary?

The Restricted Approach Boundary is the distance from an exposed energized electrical conductor or circuit part within which there is an increased likelihood of electric shock due to electrical arc-over combined with inadvertent movement.

What is Category 2 arc flash?

In PPE CAT 2, workers need the following clothing: Required Clothing: Arc Rated Long Sleeve Shirt and Pants or Arc Rated Coverall with minimum arc rating of 8 cal/cm. 2. Required AR Face and Head Protection: Arc Rated Arc Flash Suit Hood or AR Face Shield, Sock Hood/Balaclava with minimum arc rating of 8 cal/cm. 2.

What are the 2 shock boundaries?

There are two shock protection boundaries; the Limited Approach Boundary (LAB) and the Restricted Approach Boundary (RAB), and one Arc Flash Boundary (AFB) that must be established in order to provide a safe distance for personnel from exposed, energized electrical components.

What is required in a flash protection boundary?

The area closest to the live, exposed equipment is within the restricted boundary. In order to pass this boundary, you must be a qualified worker with the proper training and PPE. If you need to perform work on the energized equipment, you may also need a work permit and documentation.

What is a flash protection boundary?

Flash Protection Boundary (outer boundary): The flash boundary is the farthest established boundary from the energy source. If an arc flash occurred, this boundary is where an employee would be exposed to a curable second degree burn (1.2 calories/cm2).

What is limited approach boundary for low voltage?

Limited Approach Boundary – The Limited Approach Boundary (LAB) is identified as the “distance from an exposed energized electrical conductor or circuit part within which a shock hazard exists”. Best practice if for any unqualified person to stay 42” (3′ 6”) or more away from the hazard.

Article first time published on

How many arc flash boundaries are there?

NFPA 70E is the major industrial standard for safe electrical work in the United States. It defines three protective boundaries around electrical equipment.

What causes arc flash?

In less than a second, an arc flash is initiated from a phase to ground or a phase to phase fault. It can result from accidental contact with the electrical systems, the buildup of conductive dusts, corrosion, dropped tools, or improper work procedures.

What is HRC level?

The risk levels are from 1 to 4; HRC level 1 is low risk and HRC 4 is the highest and most dangerous risk level. Level 0 is little to no risk and Level 4 is extreme risk. Which leads to the question what is an HRC? An HRC level is determined by the minimum amount of calories per square centimeter (ATPV or Cal/cm2).

How are arc flash boundaries typically determined?

Calculating an arc flash boundary is going to be based on the voltage of the equipment that would cause the arc flash. … Most companies will use software programs where they can enter in the voltage information about a piece of equipment, and it will calculate the arc flash boundary automatically.

What does NFPA 2112 mean?

NFPA 2112: Standard on Flame-Resistant Clothing for Protection of Industrial Personnel Against Short-Duration Thermal Exposures from Fire.

How are arc flash and electric shock protection boundaries determined?

Limited and Restricted Approach boundaries deal with shock and are determined by NFPA 70E Tables 130.4(C)(a) for AC systems and 130.4(C)(b) for DC systems, while Arc Flash boundaries are determined through an Arc Flash Analysis or through the use of the use of the Arc Flash PPE Categories in 130.7(C)(15)(a).

What are the three hazards of arc flash?

An arc flash can cause minor injuries, third degree burns and potential death as well as other injuries including blindness, hearing loss, nerve damage and cardiac arrest.

What is the arc flash boundary for 480v?

The earlier mentioned voltages of 208, 220, 240, 277, 380, and 480 volts AC have a restricted boundary of 12 inches.

What is the restricted approach boundary for a 480v system?

Referencing the table for a 480-volt AC system yields a Limited Approach Boundary of 1 meter or 3 feet 6 inches and a Restricted Approach Boundary of 30 centimeters or 12 inches. Qualified workers must also be able to determine the Arc Flash Boundary for the job task they intend to perform.

What boundaries are typically shown on the are flash labels?

Nominal voltage, limited and restricted approach boundaries, and PPE glove rating are also displayed on the label to help protect workers from electric shock.

What does wires arcing mean?

Electrical arcing is when electricity jumps from a one connection to another. This flash of electricity reaches temperatures of 35,000°F. … This is arcing. The heat from arcing burns the insulation around the wires, leaving a path for the arcing to reach insulation or wood framing in your home.

What is an arc burn?

Arc burn. This type of burn occurs when electrical energy passes from a high-resistance area to a low-resistance area. No contact is required with an arc burn as the electricity ionizes air particles to complete the circuit.

What causes an electrical explosion?

Electrical blast (or explosion) is the result of the rapid expansion of air caused by an electric arc: … Caused by superheating of air and vaporizing of conductors (air expands to roughly 1670 times and copper expands to roughly 67,000 times its volume – i.e. 1 in3 becomes 1.4 yd3)

What is an arc rating?

Arc rating is defined as the amount of energy a given fabric can withstand before a 50 percent likelihood of the onset of second-degree burn through the fabric.

What are arc flash ratings?

The Arc Rating is the maximum incident energy resistance demonstrated by a material prior to break open (a hole in the material) or necessary to pass through and cause with 50% probability a second or third degree burn.

What does arc rating mean?

One common question we receive is “what is arc rated?” As it applies to flame resistant (FR) garments and personal protective equipment (PPE), arc rated means that the material has been tested for exposure to an electrical arc and assigned a value according to its performance.
