What is 56y frame

The “frame” means where do the bolts fit that attach the wet end to the motor. Most of the time you can find the frame listed on the label as either 48 or 56. Often with an F indicating that is the “frame” size. If you cannot find an indication of frame size you can measure between the thru-bolts on the pump.

What does frame mean on a pump?

The “frame” means where do the bolts fit that attach the wet end to the motor. Most of the time you can find the frame listed on the label as either 48 or 56. Often with an F indicating that is the “frame” size. If you cannot find an indication of frame size you can measure between the thru-bolts on the pump.

What type of shaft does a 56Y frame motor have?

Its large 6.5 frame boasts a stainless steel shaft for extremely durable housing and its thermally protected, Class B insulated design keeps the motor cool to prevent overheating.

What does 56C frame mean?

Machine builder Richard J. Kinch says the “C” in “56C” stands for a flange or faceplate mounting system. The four mounting points are on the face of the motor, where the shaft comes out. This mounting arraignment is very useful.

Can I replace a 48 frame spa pump with a 56 frame?

Almost all spa pumps are manufactured in one of two standard frame sizes: 48-Frame and 56-Frame. If you want to replace your wet end or your motor, you should use an equivalent of the same size, so that the mounting holes between the motor and the wet end align.

What does 48 frame pump mean?

48-Frame motors are basically pool motors, not designed for the rigors of hot tubs with their high-pressure massage jets. … Specifically “Frame” refers to the diameter of the armature in the motor. Although 2 motors may have the same horsepower rating, a 56-Frame motor will be 40% larger.

What is pump frame size?

Hot tub pumps typically come in two different frame sizes: 48 frame and 56 frame. When replacing a hot tub pump, it is important to replace it with the same size pump so that the holes and plumbing will line up.

What is a 184 frame motor?

A motor’s frame size is a reference to the size of the mounting footprint, shaft diameter, and shaft length. These motors are all frame size 184. In terms of mounting, these motors can replace each other and other motors with the same frame size.

What is a 48Y frame?

The Flex-frame motors are usually labeled as 48Y, but will have the distinct pedestal at its base. The Flex is unique because it uses four thin partially threaded screws (known as thru bolts) that are slid the length of the motor through the back end and screwed into the seal plate.

What is S56C frame?

SS56C motors have a 4.88 inch diameter frame. S56C motors have a 5.61 inch diameter frame.
