What is Delrin used for

Parts exposed to a moist or wet environment, such as pump and valve components, are especially appropriate. Other common uses include gears, bearings, bushings, rollers, fittings, and electrical insulator parts.

What is Delrin material used for?

Polyoxymethylene (POM) injection molding material, often referred to as Delrin® or acetal is an engineered thermoplastic material that is used to manufacture parts that require increased stiffness, low friction versatility and greater dimensional stability.

What is another name for Delrin?

Acetal is the common name for a family of thermoplastics with the chemical name “PolyOxyMethylene”, or POM. Acetal is available in two general types of resins: Copolymer acetal (POM-C), and homopolymer acetal (POM-H); commonly called Delrin®.

Is Delrin expensive?

In addition to its properties – Delrin is a relatively inexpensive material compared to PTFE and even PA66. This makes it a sought after choice in machined component development – as the parts are dimensionally very stable and significant trials can be done without being too expensive.

Is Delrin stronger than nylon?

Despite these similarities, nylon is generally stronger than Delrin. Extruded nylon has a tensile strength of 12,400 PSI and cast nylon has a tensile strength of between 10,000 and 13,500 PSI. In contrast, Delrin has a tensile strength of 10,000 PSI.

Can Delrin be cast?

Therefore, DELRIN® acetal resins frequently can replace die-cast alloys, brass and sheet metal on both cost and performance basis.

Can you machine Delrin?

It’s true that Delrin is an easy material to work with in terms of machining. It is a very stable material, which makes precise, tight tolerances easier to achieve for this thermoplastic. While machining, keep in mind that Delrin is sensitive to heat at or above 250 °F (121°C).

Does Delrin melt?

The recommended melt temperature for Delrin® is 215+/-5ºC highlighted area) at which the melt for standard grades will remain perfectly stable for over 30 minutes.

Is Delrin brittle?

Thermal Properties Delrin does not use plasticizing for toughness: and so does not become brittle at low temperatures. Impact resistance at -40° F is only 20% less than that at room temperature.

What kind of plastic is Delrin?

Delrin is a trademarked name for acetal resins that are semi-crystalline thermoplastic polymers. This type of material is also known by the abbreviation POM or polyoxymethylene. It has gained popularity since first being introduced to the commercial marketplace in 1960.

Article first time published on

How do you glue Delrin?

1. Step 1: Prepare You Pieces for Glueing. Before you glue your pieces of derin together you will want to pre pare them. First scratch up the surfaces with some sand paper. …
2. Step 2: Apply Glue. Go2 glue from locktite works great for bonding derin together. Use a drop on the surface. …
3. 5 Comments. BillR130.

What color is Delrin?

Delrin sheet available in 8 standard colors: blue, green, red, orange, yellow, purple, fluorescent green and fluorescent pink. Ensinger’s Delrin® colored sheets are a homopolymer Acetal manufactured using DuPont Delrin® 150 Resin.

What temperature does Delrin melt?

Delrin® acetal resin is a crystalline resin with a melting point of 177°C (350°F). The preferred melt temperature range is 205–225°C (400–440°F) for standard grades and 195–215°C (383–420°F) for impact modified grades (Delrin® 100ST and Delrin® 500T).

Is Delrin good for gears?

The most widely used DuPont resin for gears, Delrin® provides strength and stiffness without the need for glass fiber reinforcement. … The first engineering polymer for gears, Zytel® offers exceptional strength, toughness, temperature resistance, and excellent moldability.

What is the hardest wearing plastic?

UHMW (a soft, tough plastic) offers outstanding abrasion resistance. Nylon and Acetal (both stronger than UHMW) are often used for applications that require superior mechanical properties.

Is Delrin a Teflon?

Delrin is a thermoplastic material, unlike Teflon. Teflon is made of polytetrafluoroethylene. Whereas, Delrin is composed of polyoxymethylene. Teflon has dielectric properties and is used in electric circuits.

What durometer is Delrin?

SpecificationTestValueHardness, Durometer (Shore “D” scale)D2240D83Hardness, Rockwell (Scale as noted)D785115Izod Impact, Notched @ 73°FD256 Type A0.7Coefficient of Friction (Dry vs Steel) StaticPTM 550070.20

Can you CNC Delrin?

Delrin 100 Due to its high impact resistance and low friction characteristics, CNC machined Delrin is ideal for gears, door system components, and bushings. … Delrin can also maintain its properties across a temperature range of -40oC to 120oC, which is a much bigger range than most other plastics can tolerate.

Is Delrin hard or soft plastic?

Delrin® plastic is strong, rigid, and resistant to impact, creep, abrasion, friction, and fatigue. It’s also well known for its excellent dimensional stability during high-precision machining.

Is Delrin flexible?

Delrin® provides dimensional stability in high precision molding and flexibility of design.

Is Delrin self lubricating?

Well-Known Member. delrin is self lubricating but if you want to grease it go ahead. delrin is one of the most chemically resistant plastics there is. no grease will hurt it.

Does Delrin shrink?

For Delrin® standard grades, a mold temperature of 80–100 °C (176–212 °F) is recommended as good compromise. For high precision parts, a higher mold temperature up to 120 °C (248 °F) might be necessary. Note: High mold temperatures and thick part sections may increase shrinkage.

How good is Delrin?

Excellent resistance to moisture, gasoline, solvents, and many other neutral chemicals. Excellent dimensional stability. Good resilience and resistance to creep. Natural lubricity.

Can Delrin be extruded?

Because Delrin is a thermoplastic, stock shapes and finished parts can also be melted and remolded or extruded several times as needed.

Is Delrin Food Safe?

Despite having a relatively high cost when compared to unfilled Acetal, it is widely used and specified. …

Who manufactures Delrin?

Authentic Delrin® acetal homopolymer is available exclusively from DuPont, authorized DuPont distributors, and from stock shape suppliers in a variety of forms (sheets, rods, tubes).

What Delrin 500?

DELRIN®500AF blend stock shapes are a 20% PTFE fiber filled homopolymer acetal. It is designed for applications requiring low wear and and/or low coefficient of friction against steel, itself, and other plastics.

Is Delrin stronger than acrylic?

As far as durability, Delrin is WAY tougher than acrylic.

How is Delrin synthesized?

Delrin is produced by the polymerization of anhydrous formaldehyde through anionic catalysis. This method causes the creation of a centerline porosity in cross sections of the polymer material. This region is called a low-density centre due to this porosity.

Is Delrin a ESD?

It is available in ESD-Safe delrin plastic. The tip prevents static and mechanical damage. It requires a continuous vacuum source.

Can you superglue Delrin?

Delrin or acetal or polyoxymethylene, otherwise known as acetal or POM, have slick surfaces which make them hard to penetrate and therefore glue. This slick surface is a result of its low surface energy.
