What is the difference between a lockshield and radiator valve

The Lockshield valve restricts hot water flow to radiators to help balance the entire system as a whole. Other radiator valves can be used to help adjust the temperature of a radiator to help heat or cool a room.

Do all radiators have a lockshield valve?

Unless your radiators have TRVs fitted, they will usually have a wheelhead and a lockshield valve, one on each end.

Should lockshield valve be open or closed?

When the radiators are cool, switch the heating back on and go to the first radiator on your list. Turn the lockshield valve clockwise until it is closed and then open it by a quarter of a turn. Once the radiator has warmed up, take a temperature reading at the pipework leading to one of the valves (7).

Which radiator valve is the lockshield?

Lockshield valves explained The lockshield valve, on the side of the radiator opposite the on/off valve, may be adjusted to balance the output of your heating system. The lockshield itself is the plastic cap that covers the valve to ensure that you don’t accidentally change the setting once you’ve adjusted it.

What are lockshield valves for?

Lockshield valves are the covered valves on a radiator, usually by a plastic cap which prevents them from being accidently altered. Once this has been temporarily removed, lockshield radiator valves can be adjusted by turning the spindle to control how much water stays in or flows out of the radiator.

What happens if all lockshield valves are fully open?

On most radiators, this is the valve you can’t turn by hand. By closing a fully-open lockshield valve by a few turns (with a pair of grips or screwdriver), you can slow down the rate at which water enters the radiator and reduce the speed with which it gets hot.

Can a radiator have two lockshield valves?

As long as there is other radiators on the system and they aren’t all closed down you shouldn’t have a problem.

Which side should the lockshield valve?

Systems are normally balanced by adjusting the lockshield valves usually fitted on the return side of each radiator. This ensures that each radiator circuit in the system has an equal pressure drop and receives the correct flow of hot water to heat the space in which it is fitted.

How do I know which is the lockshield valve?

Find and familiarise yourself with the valves on your radiators. This is a lockshield valve and will usually have a push-on cap, or a cap that is secured with a screw through the top of it. Remove the cap altogether.

Why are there 2 valves on a radiator?

One valve accounts for the amount of hot water that enters the radiator. … The other valve, referred to as the lockshield valve, balances the system by regulating how much heat the radiator gives off.

Article first time published on

Do you bleed a radiator when it is on or off?

Turn off your heating. You can’t bleed a radiator when the heating is on, as it may be too hot to touch. You could also get hot water spraying out of the radiator. Use your radiator key to turn the valve at the top of the radiator.

Why are radiators hot upstairs but not downstairs?

The central heating pump pushes water from your boiler or hot water tank around your central heating system so that the water in your pipe work and radiators is constantly moving. … If your radiators are hot upstairs and cold downstairs it is most likely that your pump is not working correctly.

How do you turn on a lockshield valve?

Once the system has cooled down, you will have to open the lockshield valve. To do this, simply turn in an anti-clockwise direction (to the left). You can do so by hand; but if your valves are a bit stiff, use your lockshield valve key, a spanner, or the wheelhead valve cap instead.

What does a lockshield valve do on a radiator?

A lockshield valve is the valve on a radiator that is usually covered with a plastic cap. Lockshield valves need to be adjusted when balancing home radiators in individual rooms. A lockshield valve will balance out each radiator within your heating system, ensuring they all heat up at the same rate.

How can I balance my radiator without a thermometer?

On only the hottest radiators close the balancing valve to just over half-way open (~60%). To do this, count how many full turns it takes to fully close it and then open it by just over half as many turns. For example, if it takes 2.5 turns to go from open to closed, then close the valve and open it by 1.5 turns.

Should radiators be open on both ends?

Radiators typically have two valves located on the pipes that allow hot water to enter them. … You should open both of the valves on all of your system’s radiator when you are starting the radiator balancing process. You will most likely need to use pliers to open the lockshield valve.

Does it matter which side of radiator flow and return?

The vast majority of new TRV’s are bidirectional and can be fitted to either the flow or return, but it is always good practice to fit them to the flow side. If a non bidirectional TRV is fitted on the return side it will create a vibrating sound as the water tries to flow though it.

Why is only half my radiator hot?

Check for Trapped Air and Bleed Your Radiators If just one (or a few) of your radiators aren’t heating up, the most common reason for this is trapped air. If you’ve just turned the heating back on after the summer, air can become trapped in your radiators, causing them to be warm at the bottom but cold at the top.

How much should a lockshield be open?

You should open the Lockshield valve on the first radiator by one-quarter of a turn. Now open the Lockshield valve on the last radiator on your list. Each radiator in between should have its Lockshield valve opened slightly more than the previous radiator.

Which way do you turn a lockshield valve to open?

For Lockshield valves, remove the plastic cap (instructions above) and turn the metal valve anti-clockwise with a Lockshield valve adjuster or an adjustable spanner.

Can you turn off some radiators in unused rooms?

And it’s not a good idea to turn a radiator off permanently in an unused room, as this can lead to damp and mould. Leave them on low instead, and close the doors.

Which side of a radiator is the flow?

The flow of a radiator is typically on the left as you look at it stood up or attached to the wall.

Which side of a radiator is the inlet?

Discovering where the valve inlets on your radiator are is fairly straight-forward and is defined primarily by the kind of radiator or heated towel rail that you have. With a heated towel rail, for example, you will normally find that the inlet position is located underneath at the bottom.

Why do you have to a one radiator without a thermostat?

The thermostat controls the boiler and turns the boiler off when the air temperature (yes recorded in one place usually the hall or lounge). The radiator valves do not control the boiler and at least one radiator should be on all the time (have no control).

Do radiators have a flow direction?

Normally there is a valve on one side of the radiator, and a lock shield on the other. The valve is often the flow. If you cannot trace the pipes, the only way is to feel which pipe feeding the rad gets hot first when the boiler is first put on.

How do you fix a leaking lockshield valve?

1. Step 1 – Tighten Union Nut. …
2. Step 2 – Release the Pressure in the System. …
3. Step 3 – Freeze the Pipe Below the Lockshield Valve. …
4. Step 4 – Undo the Nut. …
5. Step 5 – Do the Nut Back Up.

Why is radiator hot at top and cold at bottom?

If you have a radiator that is getting hot at the top but cold at the bottom, it isn’t a problem with air being trapped in that rad. This is much more likely to be caused by so called ‘radiator sludge’ accumulating at the bottom of the radiator and preventing it from being heated by the hot water in your system.

What happens if you let too much water out of a radiator?

Baird warns that letting out too much water is likely to introduce fresh water into the system, which can make the situation worse as fresh water contains a lot of air. He adds: “Some people also think if a radiator is cold on the bottom but hot at the top then it needs to be bled.

What happens when you bleed a radiator and no water comes out?

If no water or air comes out when you bleed the radiator, then the valve could be blocked with paint. … Insert the radiator key into the bleed valve and slowly turn it anti-clockwise (a quarter of a turn should be enough). You should hear a hissing sound as the air escapes.

Why is 1 radiator in my house cold?

Why is one radiator cold when the heating is on? One cold radiator usually indicates that either there is air in the system or there is a stuck valve within that radiator. … To check if the valve is stuck, you can remove the rotatable head on the TRV to reveal a raised pin beneath it.

How do you balance upstairs and downstairs radiators?

1. Bleed the radiators.
2. Fully open all lockshields and thermostatic radiator valves (TRVs) and turn the central heating on.
3. After 20 minutes, feel each radiator. …
4. Check all radiators again. …
5. Repeat the process until all radiators feel the same temperature.
