What size is a 8.8 Bolt

Metric hex bolts, Zinc plated class 8.8 steel, 8mm x 1.0mm x 60mm.

What does 8.8 mean on a bolt?

So, in English, a PC 8.8 bolt is a bolt with a nominal tensile strength of 800 MPa and a nominal yield strength that is 80% of the bolt’s nominal tensile strength, or 640 MPa.

Is 8.8 high tensile?

High tensile steel bolts Grade 8.8 high tensile steel is often referred to as the structural grade for bolts. It is the most common form of high tensile material and is usually stocked in plain finish or zinc. It can be plated in many other coatings.

What size is a Ty 8.8 Bolt?

Grade and MaterialNominal Size Range (inches)Class 8.8 Medium carbon steel, quenched and temperedAll sizes below 16mm16mm – 72mmClass 10.9 Alloy steel, quenched and tempered5mm – 100mm

How much weight can a 8.8 bolt hold?

In round terms it is in 10’s of kg per square millimeter of the bolt. For example, a grade 12.9 bolt will not snap until every square millimetre of the bolt cross section is carrying a load of at least 120 kg. Similarly a grade 8.8 bolt will not snap until it is carrying a load of 80kg per square millimetre.

What size is m20?

NOMINAL SIZE (D)BODY DIAMETERm1414.0013.73m1616.0015.73m2020.0019.67m2424.0023.67

What size is a M8 bolt?

SizeClearance Hole mmTapping Drill (std Pitch)M55.54.2 mmM66.55.0 mmM896.75 mmM10118.5 mm

What grade is the strongest bolt?

Grade 9 structural bolts, also known as grade 9 hex cap screws, are one the strongest structural bolts that can be used today. While the typical grade 8 bolt has a tensile strength of 150,000 PSI, a grade 9 bolt has a tensile strength of 180,000PSI.

What is yield strength of 8.8 class bolt?

Class and MaterialNominal Size Range (mm)Mechanical PropertiesMin. Yield Strength (MPa)Class 8.8 Medium carbon steel, quenched and temperedAll sizes below 16mm64016mm – 72mm660

What are bolt grades?

The grade of a bolt determines the maximum amount of stress (tensile strength) that the bolt can handle. … The SAE marking system uses raised dashes on the bolt head to indicate strength. Metric Bolt Grades—Metric grades are set according to rules set by the ISO (International Standards Organization).

Article first time published on

Is M8 screw 8mm?

There is an M sized bolt or screw that is 8mm in diameter. It is roughly the same as a 5/16 bolt or screw.

Is 8mm same as 5 16?

8mm = 5/16 inch. 9mm = almost 3/8 inch.

What does m20 bolt mean?

M10-1.0 x 20 M = This designates the fastener is a metric size. 10 = The nominal diameter in millimeters. 1.0 = The thread pitch, or distance between threads, in millimeters. 20 = The fastener’s length, in millimeters.

What is M20 bolt size?

Diameter (d)PitchAcross Flats (s)M182.5mm27mmM202.5mm30mmM222.5mm32mmM243.0mm36mm

What does M8 mean on a bolt?

M8-1.0 x 20. Here’s what the description means… M = Metric thread designation. 8 = Nominal diameter, in millimeters. 1.0 = Pitch (distance from thread to thread), in millimeters.

What size is M20 thread?

ThreadMajor DiameterPitch DiameterM1818.016.376M2020.018.376M2222.020.376M2424.022.051

What kind of steel are Grade 8 bolts made of?

Grade 8 (SAE J429) is a medium carbon alloy steel with one of the highest tensile strengths available. With a minimum tensile strength of 150 ksi and a minimum yield of 130 ksi, Grade 8 has a higher tensile and yield strength than other steel grades such as Grade 5 and B7.

What does 1364 mean?

IS 1364 was originally published in 1960 and first revised in 1967. Subsequent to the publication of 1967 edition, many changes had been agreed upon at international level which have been reflected in IS 1367 series of standards covering ‘Technical supply conditions for threaded steel fasteners‘.

What grade is a metric 8.8 bolt?

Class 8.8 is similar to grade 5. Zinc plated for moderate corrosion resistance. A tempered medium carbon steel. Class 10.9 is stronger than class 8.8.

What are black bolts?

The term “black bolt” is an industry term for plain finish or no finish bolts. These bolts offer no corrosion resistance and will rust over time. If you are looking for a decorative coating that is actually black, you will want to specify that they are actually coated and state which kind of coating is necessary.

How can you tell if a bolt is grade 8?

English bolts have radial lines on their head to identify the grade, or strength class. The number of lines on the bolt head is 2 less than the actual grade. So, for example, a grade 5 bolt will only have 3 radial lines on its head. A grade 8 bolt will have 6 radial lines on its head.

Is Grade 8 bolts stronger than Grade 5?

Grade 8 bolts have been hardened more than grade 5 bolts. Thus they are stronger and are used in demanding applications such as automotive suspensions.

What does M mean for screws?

The standard metric rack screw is called M6 x 1. The ‘M’ means it’s metric. The ‘6’ is the outside diameter measured in millimeters, and the ‘1’ is the distance between adjacent threads, also in millimeters. Metric threads are used outside of the USA, and commonly in products by HP and other global entities.

What length is an M8 screw?

Bolt Diameter125mm and ShorterLonger Than 125mmM82228M102632M123036M143440

Will a 8mm bolt fit a 5/16 nut?

Can I use a M8 bolt on a 5/16 thread? They look pretty similar at glance… Well, quick answer is no. They are not the same and they are not interchangeable, although they can work under certain circumstances.

What is the same size as 8mm?

MMApproximate Size In InchesExact Size In Inches8mm5/16 Inch0.31496 Inches9mmJust short of 3/8 Inch0.35433 Inches10mmLittle over 3/8 Inch0.39370 Inches11mm7/16 Inch0.43307 Inches

What is a 8 mm socket equivalent to?

Bolt DiameterMetricStandard1/8″8mm5/16″3/16″10mm3/8″1/4″11mm7/16″5/16″13mm1/2″

What size is M20 in inches?

Tap sizeBasic major dia (mm)Basic major dia (inch)M18 x 1.518mm.7087M20 x 2.520mm.7874M20 x 1.520mm.7874M22 x 2.522mm.8661

How can you tell if a bolt is metric?

The metric screw thread is identified by the capital letter M, followed by the nominal diameter. Metric threads are measured by the distance between two adjacent threads in millimeters (pitch). Threads on a standard (inch based) fastener are measured by counting the number of threads per inch.

What is a M20?

M20 is a concrete mix design ratio. Here M=mix,20 is the compressive strength of a cube(15*15*15cm)made with that mix proportion. For M20 Cement:fine aggregate:coarse aggregate=1:1.5:3.

What size socket fits a M20 nut?

Bolt sizeSizeTolerance3/4″UNF1-1/8″29.1529mm29.58M2030mm30.581-3/16″30.74
