Where is the danger zone when working on a jointer

Danger Zone-The jointer danger zone is 3″ out from the cutterhead and knives and 8′ directly in front of the cutterhead. When you use the jointer, stand to the left of the machine (opposite the drive shaft) and keep your hands away from the knives. Always wear proper eye and ear protection.

What is the safety clearance on the jointer?

I. Jointer: The optimum safety zone for the jointer would be 24 feet long (side to side) and 42″ wide. This provides space for a 12-foot board.

Why is a jointer dangerous?

Second to circular saws, hand-feed jointers or surface planers are the most dangerous woodworking machines. Most injuries are caused by the hands and fingers of the operator coming in contact with the blades of the machine.

What should you not do with a jointer?

What should you avoid when using a jointer or planer? Do not cut stock that has loose knots, splits, defects or foreign objects (e.g., metal stone) in it. Do not leave the machine running unattended. Shut off the power and make sure that the cutting head has stopped revolving before leaving the area.

What should you do when you approach the jointer?

When face-jointing, this means you should orient the cup or bow downward. When edge-jointing, the crook should be at the bottom. That way, the board will ride on its high spots, providing better footing. Conversely, if you try to feed with the convex side downward, the board will rock, making control difficult.

What are 5 safety rules for a jointer?

1. Always read and follow the manufacturer’s instructions.
2. Wear ear and eye protection, and do not wear jewelry, long sleeves, or loose clothing.
3. Use paddles, push blocks, and push sticks to keep your hands 6 in.

Where is the danger zone when working on a jointer Why should it be avoided?

Danger Zone-The jointer danger zone is 3″ out from the cutterhead and knives and 8′ directly in front of the cutterhead. When you use the jointer, stand to the left of the machine (opposite the drive shaft) and keep your hands away from the knives. Always wear proper eye and ear protection.

What two places should you not put your fingers when using the planer?

Also, never plane lumber that has screws, nails, staples, etc. attached. A good “rule of thumb” is to never plane used lumber. jointer should be used to true the surface.

Is it deeper to not take cuts?

Do not take cuts deeper than 1/16 at a time. Plane one desired thickness at a time? Check all wood for splits, _______ or metal and other imperfections.

What is the maximum cut for jointing an edge?

Cuts should be no deeper than 1/8 inch per pass. To use the jointer to smooth edges, feed the wood into the tool with the rough edge facing down. Feed the wood through the jointer as many times as needed to achieve a straight edge. This process is useful for straightening a warped board.

Article first time published on

What are the parts of a jointer?

The jointer is not a complex machine, and as such its part is very simple. As simple as they are, so are their functions. The most functional parts among many others of the jointer include the infeed table, the outfeed table, the cutter head, the fence and the guard.

What depth should the jointer be set to before the power is turned on?

Always see that the jointer is set to the right depth of cut, about 1/32 inch, before you turn on the power. If it is set too deep the work may be jerked out of your hands. 3. You must not use the jointer for face work which is less than 1/2 inch thick.

When using the jointer where should you stand?

Always stand at the side of the jointer by the cutter head. All setups other than edging and facing must be approved by supervisor.

What is planer used for?

A power planer’s primary function is to smooth the surface of wood, but it can also be used to smooth wood’s rough end grain. It’s also used for tapering wood. If a door is too wide, for instance, make passes with a power planer over the side of the door, adjusting the depth gauge to give a cut of the desired depth.

What is a joiner saw?

A jointer or in some configurations, a jointer-planer (also known in the UK and Australia as a planer or surface planer, and sometimes also as a buzzer or flat top) is a woodworking machine used to produce a flat surface along a board’s length.

Whats a wood jointer do?

A jointer is used to make the face of a warped, twisted, or bowed board flat. After your boards are flat, then the jointer can be used to straighten and square edges (guard removed for photo). There’s an infeed table and an outfeed table. The tables are aligned in the same plane.

What causes kickback on a jOINTER?

A board or piece of one, resting on top of the cutter head will experience a force moving it to the operator’s right. If that force is unopposed by the operator adequately pressing the board down and to the left, the board may be thrown to the right. This motion is known as “kickback”.

What are 5 safety rules you should follow when using the hand power planer?

Safety glasses and hearing protection are required. Never wear gloves when operating planer. Don’t raise or lower table while stock is in planer. Always run dust collection with planer. Keep hands 4” away from planer infeed area.

Can you plane a warped board?

In order to flatten a warped, twisted, or cupped board, a common approach is to first use a jointer to create one perfectly flat face. Then you run the board through a thickness planer with the flat face downward, and the planer makes the top face parallel to the bottom.

What is the shortest board you are allowed to run through the thickness planer?

Technically there’s no minimum length you can send through a thickness planer if you ‘cheat’. There are various tricks that allow planing of material both too thin and too short and they can work well. After you’ve planed to thickness you simply pop the outriggers off with a chisel.

How do you stop a jointer snipe?

1. Ensure that the knives are set properly. Check carefully with a good straight edge, and be sure that the knives are set in parallel with the table. …
2. Sneak up on the adjustment. …
3. Run several tests, then lock it in tight.

Why is my jointer not cutting flat?

In some cases, this can be caused by infeed and outfeed tables that aren’t parallel. But a more common (and easier to fix) cause is an outfeed table that is just a bit higher than the jointer knives.

When pushing material on edge through a jointer It is important that your hand position is?

It is a good practice to use your left hand as the hold-in hand and the right hand as the push/pull and hold-down hand when edge jointing. However, you will have to move both hands during the process of moving the stock through the jointer. Make sure that you always have one hand on the board at all times.

What is the minimum length of workpiece that can be safely used on a jointer?

Each machine has minimum thicknesses and board (workpiece) lengths that can be safely worked on that machine. A good rule of thumb would be about ¾” minimum thickness and the minimum length of 12”.

What is bench top jointer?

A benchtop jointer is a woodworking appliance or device that is used to create flat surfaces on a piece of wood. … A benchtop jointer uses a series of knife blades to make the cuts into the wood and create beveled edges that allow for wood to fit together easier.

When using a jointer What is the recommended amount that should be removed to the desired size?

Set an appropriate depth of cut. Avoid wasting stock or overcutting by starting with a shallow depth of cut. Run a test pass, then readjust accordingly. For general use, set your machine to 1/32 inch, which is usually enough to remove saw marks on a ripped edge. A rough or badly warped board might require a deeper cut.
