Which side of Wonderboard faces out

Should I install cementitious backerboard (Durock, Wonderboard, etc.) with the rough or the smooth side facing out? A. Backerboard is usually installed rough side out when used under a thin-set mortar for slate or ceramic tile flooring, and smooth side out when it is a base for adhesive-set wall tile.

Does it matter which side of backer board faces out?

Screw the board in place Cement board has a smooth side and a rough side. Face the rough side out if you will be using thin-set mortar adhesive to install the tile but the smooth side out if you will be using latex mastic.

How do you waterproof Wonderboard?

WonderBoard® Lite is not a waterproof barrier. If the area behind the backerboard must be kept dry, use RedGard® Waterproofing and Crack Prevention Membrane or Custom® 9240 Waterproofing and Anti-Fracture Membrane Do not use drywall fiberglass tape for this product. Do not use wallboard joint compound for this product.

Is there a front and back on cement board?

Cement board manufacturers imprint a gridlike pattern on one surface of the board. … Also, cement board typically has a label or manufacturer sticker on the front of the board. The back of cement board is plain, has no manufacturer-defining stickers and is void of the front-featured grid.

How do you layout cement board?

#2 A cement backer board layout should be staggered. It’s kind of like building a wall of Lego’s. If you set each one directly on top of each other it is unstable. You create a stronger, more stable floor by staggering the backer board. Likewise, four corners of cement board should never meet at one point.

Which side of durock should face out?

Should I install cementitious backerboard (Durock, Wonderboard, etc.) with the rough or the smooth side facing out? A. Backerboard is usually installed rough side out when used under a thin-set mortar for slate or ceramic tile flooring, and smooth side out when it is a base for adhesive-set wall tile.

Which side of 1/2 Hardibacker faces out?

Which side goes up, smooth or rough? Either is acceptable, but we recommend that the smooth side with the nailing pattern of every 8″ on center go up. What subfloor should HardieBacker® cement board be installed over?

Can I use cement board around a fireplace?

You can use Hardiebacker board around your fireplace. … However, using fiber cement board like Hardieboard is acceptable in locations including the mantel and fireplace surround.

How do you install cement board around a fireplace?

Measure the fireplace surround with a measuring tape. …
Cut the cement board pieces to size. …
Spread thinset mortar over the fireplace surround with a notched trowel. …
Nail the cement board to the brick fireplace with 1½-inch concrete nails. …
Allow the thinset mortar to dry overnight, then tile the fireplace as desired.

What do you cut WonderBoard with?

Cutting Wonderboard Use a circular saw with a cement board blade. Support the entire board before and during cutting to avoid breakage. The scoring knife can be used instead of a saw for a cut that goes across the whole board. Use a straight edge and press hard as you draw the knife along the cut line.

Article first time published on

Can WonderBoard be installed vertically?

36″ x 60″ x 1/4″ 15 sq. ft. WonderBoard Lite can be used on horizontal or vertical (7/16″ only) applications such as walls, ceilings, floors, decks, countertops and vanities. Use under any tile or natural stone.

What is the difference between WonderBoard and durock?

I found that Wonderboard is stiffer than Durock (less floppy) which makes it easier to handle, carrying up stairs, loading etc. It also seemed to have a more consistent cement fill with less voids and less soft and “crumbly” areas than Durock.

What do you do with a gap between tub and cement board?

Technically, after the tile is installed over the backer board that gap between it and the tub ledge should be filled with an ASTM C920 sealant (caulking e.g. silicone). Although some say you should have weep holes along this gap so any water behind can weep out into the tub.

What is the difference between backer board and WonderBoard?

The biggest difference between HardieBacker and WonderBoard Lite is in their composition. HardieBacker is made of a blend of cement, sand, and cellulose fibers, while WonderBoard is made of a cement mixture reinforced by mesh.

Can I just screw down cement board?

Screw and Joints Do not use drywall screws as they are not recommended to be used to hold the backer board in place. All of your backer board pieces should be cut before they are placed on the floor. … It is important to highlight that screws shall not be installed all the way down to the floor joists.

Do you have to mortar under cement board?

Using thinset under cement board is a commonly skipped step amongst many contractors. … However, many manufacturers including, both Durock and Hardiebacker not only recommend that you use thinset under their backerboard, but they specify it and will void the warranty on their product if it’s not used.

What goes behind Hardieboard?

Joint flashing: James Hardie recommends that a slip sheet (joint flashing) is installed behind each butt joint in the siding. This is a 6” wide piece of weather resistive material to make sure that no water gets through.

Can I use 1/4 cement board on floors?

Both 1/4- and1/2-inch cement board are appropriate for floors. To install cement board on floors, cement board manufacturers mandate a 5/8-inch plywood subfloor or OSB underlayment. They also require a 3/4-inch subfloor where tile size exceeds 12 inches.

Whats the difference between mastic and thinset?

Mastic is a non-cementitious material that exhibits some pros and cons compared to thinset. … Thinset is much stronger structurally than mastic and a waterproof product that will not lose strength when exposed to water. Thinset is the only product that I recommend be used in showers, bathrooms and even floors.

Do I need to seal cement board before tiling?

Contrary to popular thought, tile and grout are not waterproof, and some moisture will penetrate even if sealant is used. … However, if you choose to use concrete backerboard, which is much stronger and more durable than gypsum board, a water vapor membrane must be placed underneath it or a sealant applied on top of it.

What's the difference between mortar and mastic?

Mortar is commonly used to attach tiles to drywall or flooring. … Mortar can be used with most tiles, and glass and stone tiles typically require mortar. However, mastic is specifically designed for use with ceramic tiles, and is also suitable for use with some porcelain tiles.

Is thin set a mortar?

The word “thinset” is sometimes used interchangeably with “mortar,” because it’s a type of modified mortar made specifically for tile. Thinset is made of sand, water, and cement, and can also contain additives for increased bonding, water resistance, and flexibility.

Can you put cement board over drywall for fireplace?

Add cement board to the entire area you’ll be tiling (for us, that means the floor and all 4 sides of the fireplace leaving room for wood mantle). On the ground and drywall, use thinset and screws to attach the cement board. But on the metal surround, use high heat adhesive to attach the cement boards.

Is WonderBoard fire resistant?

Fire Performance: WonderBoard® has achieved a fire resistance rating for cementitious backer units per ANSI/UL 263 and CAN/ULC S101, Report No. 21766. Flexural Strength ASTM C-947 > 750 psi 900 psi (62.9 kg/cm sq.)

Can you cover a fireplace with drywall?

To remodel your brick fireplace you can simply cover it with drywall. The end result is a smooth wall that you can paint and decorate anyway you like.

Can you use drywall around a fireplace?

Drywall + Fireplace = House Fire Unfortunately, this is highly flammable and is not an appropriate or safe fireplace surround. The sheetrock had to be removed and replaced with any type of non-combustible surround – stone, tile, marble, or metal.

Do you install cement board vertically or horizontally?

In tub and shower enclosures, ensure that the framing is adequately reinforced at the corners and ends. Boards may be installed vertically or horizontally. Edges of the board parallel to framing must be supported by a structural framing member. … Do not place cement board into the shower pan mortar bed.

Can WonderBoard be painted?

Do not paint a cement board unless you have thoroughly cleaned it first, or you may have problems with adhesion. … Unlike standard cement, which is not an ideal surface for paint adhesion, fibrous cement boards contain pores that soak in the adhesives within the paint, making the finish much more durable.

Does WonderBoard smell?

This stuff has an incredibly strong, noxious odor.

Is WonderBoard Lite cement board?

A 20% lighter fiberglass mesh-reinforced cement backerboard for residential and commercial tile, stone, slate, and thin-brick applications.

Which is better Hardibacker or durock?

HardieBacker is also the go-to choice when it comes to countertops and tile. Durock is too abrasive and can damage vinyl, porcelain, and enamel. HardieBacker does not contain any course materials, so it is the preferable choice. It has a warranty that extends over the use of vinyl tile applications.
